HS-51
SOLDERING STATION

HS-51
HS-51-220
  • RoHS10物質対応

●Speedy replacement of tips without requiring a tool.

●A setting lock feature is provided to secure the soldering temperature. This feature uses a password, and does not require a card or key.

●Features a sleep function (sleep sensitivity & time setting: 0 to 20°C & 0 to 999 minutes).

●Auto shut-off activated when a preset time elapses (setting range: 0 to 999 minutes).

●Station stacking is possible.

■Power cord:1.2 m

■Accessory: Soldering iron stand (tip cleaner)

Rated voltage / Frequency 100V AC 50 / 60 Hz(HS-51)
220V AC 50 / 60 Hz(HS-51-220)
Power consumption 80 W(soldering iron 72 W)
Heater Nichrome heater with sensor
Setting temperature 50 to 450 ℃
Standard tip Tip (with built-in heater) is sold separately.
External dimensions Station 115(W)× 98(H)× 146(D)mm
Soldering iron Length 158 mm × grip inner dia. 16 mm
Weight Station 1.8 kg
Soldering iron 28 g(not including the cord)
ESD standard Rg < 1 × 1012Ω

Manual(HS-51-220)

■Replacement parts

HS-51-1
TIP CLEANER

  • RoHS10物質対応

■For HS-51

HS-51-4
TIP CLEANER

  • RoHS10物質対応

■For HS-51

■Optional items

SOLDERING TIPS
(for HS-51)

  • * Custom-order tip shapes and sizes are possible.
  • RoHS10物質対応

When using a thin tip, adequate pre-soldering should be performed first.
(Example: HS-51B01 to HS-51B02, etc.)

HS-51B03(B type)
HS-51B01(B type)
HS-51B02(B type)
HS-51B04(B type)
HS-51B09(B type)
HS-51BC01(BC type)
HS-51BC02(BC type)
HS-51BC03(BC type)
HS-51C01(C type)
HS-51C02(C type)
HS-51C03(C type)
HS-51C04(C type)
HS-51C05(C type)
HS-51C06(C type)
HS-51D01(D type)
HS-51D02(D type)
HS-51D03(D type)
HS-51D04(D type)
HS-51D05(D type)
HS-51D06(D type)
HS-51K02(K type)

HS-32 3-2
PIN ADAPTER
