Material | Tip | Polycarbonate |
---|---|---|
Body | Stainless(SUS420J2) | |
Color | Transparent(Tip) | |
Weight | 17g | |
Replacement parts |
P-640A-1 |
Part. no | Product Name | Material | Color | Heat resistant temp. ℃ |
ESD standard Ω |
Quantity | |||
---|---|---|---|---|---|---|---|---|---|
A | B | Tip width | |||||||
P-640J-1 | ESD ELASTOMER TIP |
48 | 10 | 1.5 | Polypropylene + Elastomer |
Black + gray |
- | 1×104≦Rp<1×1012 | 2-piece set |
P-642J-1 | 1.5 (R-type) |
||||||||
P-643J-1 | 3.0 (R-type) |
||||||||
P-645J-1 | 6.0 (R-type) |
||||||||
P-640S-1 | ESD Tip |
1.2 | PEEK*1 | Black | 315 | ||||
P-641S-1 | 0.4 | ||||||||
P-642S-1 | 1.0 (R-type) |
||||||||
P-643S-1 | 47 | 2.4 (R-type) |
|||||||
P-644S-1 | 48 | 0.6 | |||||||
P-645S-1 | 6.0 | ||||||||
P-640P-1 | Plastic Tip |
1.2 | PBT*2 | White | - | - | |||
P-644P-1 | 0.6 | ||||||||
P-643N-1 | Non-Stick Tip |
46 | 2.4 (R-type) |
HDPE*3 | White (Translucent) |
- | - | ||
P-645N-1 | 48 | 6.0 |
*1 PEEK (polyether ether ketone) is an engineering plastic that has particularly good mechanical properties and heat resistance.
*2 PBT(poly butylene terephthalate)is an engineering plastic that has particularly good mechanical properties and heat resistance.
*3 HDPE:High Density Polyethylene.
